Thaismart TSPT-PCS20-30 Series

Three phase ESS & Power Conversion System Bi-Directional On-Off grid Inverter

  • 100% unbalance output, each phase; Max. output up 120% rate power.
  • DC couple and AC couple to retrofit existing solar system.
  • Max.4pcs parallel for on-grid and off-grid(Optional)
  • Built in Output isolate transformer, High efficiency >95%.
  • Built in MPPT Solar controller, Charging current of 60-90A.
  • Double built in2static transfer switch inverter and bypass.
  • Zero transfer time <10ms.
  • On grid Enable/Disable HMI set &Communication eternal controller.
  • Compatible with lead acid or lithium Ion battery
  • Fan cooling & low noise. IP20, Tower designed and strong.
  • Support strong energy from diesel generator.
  • Support energy management system Building, Hospital, University, etc.
  • Power dispatching and demand side response management.
  • Distributed virtual power station management.
  • Certificated IEC62116, IEC61272, ISO9001, ISO14001
  • PEA standard B.E. code 2559
